    Aluminium Profile Roofing Sheet Roll Forming Machine For Building Panel

    Ask Lasest Price
    Brand Name : CHBEST
    Model Number : YX-915
    Certification : CE BV SGS
    Price : USD6500-25500/set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20sets/month
    Delivery Time : 5-60days
    • Product Details
    • Company Profile

    Aluminium Profile Roofing Sheet Roll Forming Machine For Building Panel

    Aluminium Profile Roofing Panel Roll Forming Machine For Building Sheet


    1. Main Advantages:

    1. Use 450H Beam as machine frame.

    2. can use more than 10 year without any problem.

    3. Use first brand PLC,trandsducer,Touch Screen.

    4. 2 years Warranty.


    2. Parameters:

    1
    Forming size
    Length
    Width
    Height
    Ordinary tile
    5000-5500mm
    1400-2300mm
    1300-1500mm
    Glazed tile
    5000-7500mm
    1400-1500mm
    1300-1500mm
    2
    Raw material
    Suitable material
    Coloerd steel coil,Galvanized coil,Aluminum coil
    Feeding width
    1000mm(Can be customized)
    Thickness
    0.3-0.8mm
    3
    Effective width
    Ordinary
    740-1250mm
    Can be customized
    4
    Rollers
    Material
    45#Steel plated with chrome
    Rows
    11rows(Determined by the required equipment)
    5
    Shafts
    Material
    45#Steel
    Diameter
    Φ70mm
    6
    Cutting blade
    Hydraulic cutting,Cr12 with quenching treatment
    7
    Capacity
    8000-40000mm/min
    8
    Weight
    3-6T(Determined by the required equipment)
    9
    Control system
    PLC control system with transducer inside
    10
    Machine body
    H-shape steel:300-450mm
    11
    Middle plate
    14-20mm(Determined by the required equipment)
    12
    Chain
    1-2Inches
    13
    Shear blade heat treatment
    HRC58-60 degree
    14
    Length precision
    ±2mm
    15
    Power of hydraulic station
    3kw(Determined by the required equipment)

    3. Machine details

    1) Manual Uncoiler:

    Usage: It is used to support the steel coil and uncoil it The steel coil is expansion by hand.
    Loading capacity: 5T
    Inner diameter: 450-508mm

    Wall Tiles Making Machine

    2) Feeding Table:

    Put the raw material (steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.


    3) Main Roll Forming Machine:

    It is designed according to the customers’ profile drawing. It adopts motor reducer drive, chain transmission, roller surfaces polishing, hard plating, heat treatment and galvanization treatment. The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped

    4)Hydraulic System:

    It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank, the pump drives the cutter machine to begin the cutting job.Power:4kw Hydraulic oil: 40#
    Components: The system includes a set of hydraulic tank, a set of hydraulic oil pump, and two hydraulic pipes. And two sets of electromagnetism valves.With reducer combination, long life, high precision

    5) Shearing Mechanism:

    It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. Material of blades: Cr12
    Components: It contains one set of cutting tools, one hydraulic tank and one cutter machine.

    Roofing Tile Making Equipments

    6) Computer Control Cabinet:

    It adopts Delta/Siemens PLC to control. The target piece’s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use.Touching screen


    4. Aftersales service:

    This producing line is maintained free of charge for 18 months. When the machine is used in China, we will install and debug the machine for free; if it is used at abroad, we will send the professional technician to debug. Buyers should take all the fees for technicians travelling abroad, including 100usd/day labor cost ,round-trip flight ticket and accommodation there.


    5. Installation and Training:

    ① If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
    ② Without visiting, we will send you user manual and video to teach you to install and operate.
    ③ If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.


    We can produce according to your requirements.
